Portable Equipment


LT50 Hydraulic - Produce Faster, Perform Better
The LT50 will take charge when your sawing demands require high productivity and easier log handling. Featuring high-quality hydraulics and packed with power, this rugged, reliable mill is ready for any challenge.

Produce Faster, Perform Better
  -  Heavy duty Bi-directional chain turner
  -  Faster head travel than the LT40s
  -  Deluxe Accuset2 Setworks standard

The Wood-Mizer Difference
  - The trapezoid shaped bed design makes blade changes and offbearing easier.
  - Odd shaped, knotty logs are easier to saw with the open sided sawing head.







Powerful bi-directional chain turner
Board Return offbears boards for you
Full Mobility with the Wireless Control Option








Specifications
Dimensions (With Trailer Package)
Length 26’-2” (8m)
Width 6’-6” (2m)
Height (max head position) 11' (3.3m)
Weight (with heaviest power options) 4370lbs (1982kg)

Power Options
38 HP (28.1kW) Gasoline Standard
47 HP (35kW) Diesel Optional
25 HP (18.5kW) 3 phase electric Optional

Maximum Cutting Capacities
Log Lengths 21' (6.4m) and up to 45' (13m) w/ BX
Log Diameter 36” (91cm)
Production Rates up to 700 BF/HR

Operation
Operator Position Walk Along
Ride Along (Optional)
Stationary (Optional)
Wireless (Optional)
Feed System 12V Electric - Power Feed
Head Up/Down 12V Electric
Computer Setworks Accuset2
Log Loading Hydraulic Loading Arms
Log Turning Hydraulic Bi-Directional Chain Turner
Roller Toeboards 2 Hydraulic Roller Toeboards
Log Clamp Hydraulic Two-Plane Clamp
Board Return System Return Arm & Receiving Table
Blade Engage Electric
Blade Lubrication Auto
Blade Tensioning Hydraulic Crank
Blade Arm In/Out Electric

Other Specs
Outriggers Quick-Set Adjustable Outriggers
Blades .045” (1.14mm) thick x 1.25” (32mm) wide
.055” (1mm) thick x 1.25” (32mm) wide
.045” (1.14mm) thick x 1.5” (32mm) wide
.055” (1mm) thick x 1.5” (32mm) wide
Warranty/Money Back Guarantee 5 yr Chassis, 2 yr Limited/30 Day


Sawmill Features Standard Optional
2 Hydraulic and 2 Manual Adjustable Side Supports -
Electric Adjustable Blade Guide Arm -
Auto Water Lube System -
Quick-Set Adjustable Outriggers -
Trailer Package -
Hydraulic Loading Arms -
Electric Blade Engage -
Hydraulic Log Clamp -
Hydraulic Bi-directional Chain Turner -
Hydraulic Roller Toeboards -
Board Return Arm -
Debarker -
Wireless Remote Control -
Stationary Command Control with Accuset 2 -
Fine Adjust Outriggers -
Lathe-Mizer -
LubeMizer -
Shingle & Lapsider -
Resaw Attachment -
Bed Extensions (6', 12', 24') -
